LED Configurator

Design your custom GLOOSA video wall in minutes. Pick a pixel pitch, size the wall in cabinets, choose mounting and processor, and export a PDF specification you can share with your team.

Step 01

Pixel Pitch & Series

Series

Pixel Pitch

Step 02

Wall Size

Target width (m)Target height (m)

Cabinets can never exceed the wall: maximum 6 wide × 7 high for this wall. FHD/UHD presets are capped to the wall size.

Cabinets wide3.60 m

Cabinets high1.01 m

Live Preview

Wall 4.00 × 2.50 m

36% covered

3.60 m × 1.01 m6 × 3 = 18 cabinets4 data ports

Step 02a

View Options

Toggle visual layers on the Scene Preview and the right-hand specification.

Step 02b

Scene Preview

3.60 m

1.01 m

3.60 m × 1.01 m

6 × 3 cabinets

Sample content

Step 03

Application

Step 04

Mounting

Step 05

Video Processor

Power & signal planning

Input voltageCable limit (A)Load allowance (%)Pixels per data port

Keep cable loops within each column

Power feeds 1 · 49 cabinets/feed

Data ports 4 · 5 cabinets/port

Capacity and component counts are planning inputs, not verified controller ratings. Confirm with GLOOSA engineering.

Fiber converter

Spare parts & bill of materials

Include spare parts

Spares (%)Modules / cabinetPSUs / cabinetCards / cabinetHub boards / cabinet

Item	Installed	Spare	Total
LED cabinets	18	1	19
LED modules	72	4	76
Power supplies	18	1	19
Receiving cards	18	1	19
Hub boards	18	1	19
Internal data links	14	0	14
Data home runs	4	0	4
Power feeds	1	0	1

Step 06

Your Details

Required to download your configuration PDF.
